Gravity-driven membrane (GDM) filtration has been investigated for almost 10 years. The technology is characterized not only by relatively lower transmembrane pressures which can be achieved by gravity (extremely low energy consumption), but also by the phenomenon of flux stabilization: A biofilm is allowed to form on the membrane and a stabilization of flux occurs which is related to biological processes within the biofilm layer on the membrane. This enables stable operation during a year or longer without any cleaning or flushing. Initially, the technology was developed mainly for household drinking water treatment, but in the meantime, the research and application has expanded to the treatment of greywater, rainwater, and wastewater as well as the pretreatment of seawater for desalination. This review covers the field from the rather fundamental research on biofilm morphology and microbial community analysis to the impact of feedwater composition, process parameters and organic removal performance. Not only household applications, but also for community-scale treatment and full-scale applications are discussed. In addition, the application potential is highlighted in comparison to conventional ultrafiltration. Finally, an overall assessment is illustrated and the research and development needs are identified.

Cyanobacterial bloom events that produce natural toxins occur in freshwaters across the globe, yet the potential risk of many cyanobacterial metabolites remains mostly unknown. Only microcystins, one class of cyanopeptides, have been studied intensively and the wealth of evidence regarding exposure concentrations and toxicity led to their inclusion in risk management frameworks for water quality. However, cyanobacteria produce an incredible diversity of hundreds of cyanopeptides beyond the class of microcystins. The question arises, whether the other cyanopeptides are in fact of no human and ecological concern or whether these compounds merely received (too) little attention thus far. Current observations suggest that an assessment of their (eco)toxicological risk is indeed relevant: First, other cyanopeptides, including cyanopeptolins and anabaenopeptins, can occur just as frequently and at similar nanomolar concentrations as microcystins in surface waters. Second, cyanopeptolins, anabaenopeptins, aeruginosins and microginins inhibit proteases in the nanomolar range, in contrast to protein phosphatase inhibition by microcystins. Cyanopeptolins, aeruginosins, and aerucyclamide also show toxicity against grazers in the micromolar range comparable to microcystins. The key challenge for a comprehensive risk assessment of cyanopeptides remains their large structural diversity, lack of reference standards, and high analytical requirements for identification and quantification. One way forward would be a prevalence study to identify the priority candidates of tentatively abundant, persistent, and toxic cyanopeptides to make comprehensive risk assessments more manageable.

Chlorine dioxide (ClO₂) is commonly used as an alternative disinfectant tochlorine in drinking water treatment because it produces limited concentrations of halogenatedorganic disinfection byproducts. During drinking water treatment, the primary ClO₂ byproductsare the chlorite (50−70%) and the chlorate ions (0−30%). However, a significant portion of theClO₂ remains unaccounted for. This study demonstrates that when ClO₂ was reacting withphenol, one mole of free available chlorine (FAC) was produced per two moles of consumed ClO₂. The in situ formed FACcompleted the mass balance on Cl for inorganic ClO₂ byproducts (FAC + ClO₂¯+ ClO₃¯). When reacting with organic matterextracts at near neutral conditions (pH 6.5−8.1), ClO₂ also yielded a significant amount of FAC (up to 25%). Up to 27% of thisin situ formed FAC was incorporated in organic matter forming adsorbable organic chlorine, which accounted for up to 7% ofthe initial ClO₂ dose. Only low concentrations of regulated trihalomethanes were produced because of an efficient mitigation oftheir precursors by ClO₂ oxidation. Conversely, dichloroacetonitrile formation from ClO₂-induced generation of FAC washigher than from addition of FAC in absence of ClO₂. Overall, these findings provide important information on the formationof FAC and disinfection byproducts during drinking water treatment with ClO₂.

Increasing transmembrane pressure (TMP) can compress and increase the hydraulic resistance of membrane biofilms. The purpose of the present study is to evaluate how compression of membrane biofilms occurs and how structural rearrangement can affect hydraulic resistance. Biofilms with heterogeneous and homogeneous physical structures were grown in membrane fouling simulators (MFS) in dead-end mode for 20 days with either (i) a nutrient enriched condition with a nutrient ratio of 100:30:10 (C: N: P), (ii) a phosphorus limitation (C: N: P ratio: 100:30:0), or (iii) river water (C: N: P ratio: ca. 100:10:1). The structural and hydraulic response of membrane biofilms to (a) changes in transmembrane pressures (0.06-0.1-0.5-0.1-0.06 bar) and (b) changes in permeate flux (10-15-20-15-10 L/m²/h) were investigated. Optical coherence tomography (OCT) was used to monitor biofilm structural response, and OCT images were processed to quantify changes in the mean biofilm thickness and relative roughness. Nutrient enriched and river water biofilms had heterogeneous physical structures with greater surface roughness (Ra' > 0.2) than homogeneous P limiting biofilms (Ra' < 0.2). Compression of biofilms with rough heterogeneous structures (Ra' > 0.2) was irreversible, indicated by irreversible decrease in surface roughness, partial relaxation in mean biofilm thickness and irreversible increase in hydraulic resistance. Compression of homogeneous biofilm (Ra' < 0.2) was on the other hand reversible, indicated by full relaxation of the biofilms structure and restoration of initial hydraulic resistance. Hydraulic response (i.e., change in the specific biofilm resistance) did not correspond with the change in physical structure of heterogeneous biofilms. The presented study provides a fundamental understanding of how biofilm physical structure can affect the biofilm's response to a change in TMP, with practical relevance for the operation of GDM filtration systems.
