Research on the distribution and effects of particulate plastic has intensified in recent years and yet, due to analytical challenges, our understanding of nanoplastic occurrence and behaviour has remained comparatively elusive. However, process studies could greatly aid in defining key parameters for nanoplastic interactions within and transfers between technical and environmental compartments. Here we provide a method to synthesize nanoplastic particles doped with a chemically entrapped metal used as a tracer, which provides a robust way to detect nanoplastics more easily, accurately and quantitatively in complex media. We show the utility of this approach in batch studies that simulate the activated sludge process of a municipal waste water treatment plant and so better understand the fate of nanoplastics in urban environments. We found that the majority of particles were associated with the sludge (>98%), with an average recovery of over 93% of the spiked material achieved. We believe that this approach can be developed further to study the fate, transport, mechanistic behaviour and biological uptake of nanoplastics in a variety of systems on different scales.

Sensor drift is commonly observed across engineering disciplines, particularly in harsh media such as wastewater. In this study, a novel stabilizing controller for nitrification of high strength ammonia solutions is designed based on online signal derivatives. The controller uses the derivative of a drifting nitrite signal to determine if nitrite-oxidizing bacteria (NOB) are substrate limited or substrate inhibited. To ensure a meaningful interpretation of the derivative signal, the process is excited in a cyclic manner by repeatedly exposing the NOB to substrate-limited and substrate-inhibited conditions. The resulting control system successfully prevented nitrite accumulations for a period of 72 days in a laboratory-scale reactor. Slow disturbances in the form of feed composition changes and temperature changes were successfully handled by the controller while short-term temperature disturbances are shown to pose a challenge to the current version of this controller. Most importantly, we demonstrate that drift-tolerant control for the purpose of process stabilization can be achieved without sensor redundancy by combining deliberate input excitation, qualitative trend analysis, and coarse process knowledge.

Sensor maintenance is time-consuming and is a bottleneck for monitoring on-site wastewater treatment systems. Hence, we compare maintained and unmaintained sensors to monitor the biological performance of a small-scale sequencing batch reactor (SBR). The sensor types are ion-selective pH, optical dissolved oxygen (DO), and oxidation-reduction potential (ORP) with platinum electrode. We created soft sensors using engineered features: ammonium valley for pH, oxidation ramp for DO, and nitrite ramp for the ORP. Four soft sensors based on unmaintained pH sensors correctly identified the completion of the ammonium oxidation (89–91 out of 107 cycles), about as many times as soft sensors based on a maintained pH sensor (91 out of 107 cycles). In contrast, the DO soft sensor using data from a maintained sensor showed slightly better (89 out of 96 cycles) detection performance than that using data from two unmaintained sensors (77, respectively 82 out of 96 correct). Furthermore, the DO soft sensor using maintained data is much less sensitive to the optimisation of cut-off frequency and slope tolerance than the soft sensor using unmaintained data. The nitrite ramp provided no useful information on the state of nitrite oxidation, so no comparison of maintained and unmaintained ORP sensors was possible in this case. We identified two hurdles when designing soft sensors for unmaintained sensors: i) Sensors’ type- and design-specific deterioration affects performance. ii) Feature engineering for soft sensors is sensor type specific, and the outcome is strongly influenced by operational parameters such as the aeration rate. In summary, the results with the provided soft sensors show that frequent sensor maintenance is not necessarily needed to monitor the performance of SBRs. Without sensor maintenance monitoring smalls-scale SBRs becomes practicable, which could improve the reliability of unstaffed on-site treatment systems substantially.

Passive sampling is a well-established tool for monitoring time-weighted average concentrations of polar and semi-polar organic contaminants in streams at flow velocities between 0.1 and 0.4 m s⁻¹. However, its application under low-flow conditions (10⁻⁵ to 0.01 m s⁻¹) – as encountered in hyporheic zones – has been scarcely reported. In this study, 3 novel passive sampler configurations were developed for the monitoring of (semi-)polar organic pollutants and related transformation products across the water-sediment interface and thus across varying hydrodynamic conditions. Their design was inspired by Chemcatcher and diffusive gradients in thin films for organics. To determine the most optimal sampler design, an uptake experiment was completed involving the 3 novel passive sampler configurations and a reference Chemcatcher in polar configuration. The experiments consisted of a circular flume that simulated the main channel of a stream and an aquarium with stagnant water that represented the underlying hyporheic zone. The systems were exposed to 192 organic pollutants at environmental concentrations, and the samplers were then collected, extracted and analyzed using liquid chromatography high-resolution mass spectrometry after 2, 6 and 14 days. The configuration that was most insensitive to different hydrodynamic conditions consisted of a reversed-phase sulfonated styrenedivinylbenzene disk as the receiving phase that was covered by an agarose diffusion gel and topped with a polyethersulfone membrane filter. To further evaluate its environmental application, samplers were installed downstream of a sewage treatment plant located at an urban stream in Berlin, Germany (Erpe). The samplers were mounted on custom-made holders which were subsequently embedded in the stream bed to position samplers above (0.30 m) and within the sediment (−0.15/-0.30/-0.45 m) for 11 days. Target and suspect screening workflows were then applied to identify common concentration patterns and link parent attenuation to transformation product formation. A total of 104 concentration profiles were determined, suggesting the efficiency of the proposed sampling strategy in the water-sediment interface. Valsartan acid was the only known transformation product indicative of hyporheic zone-driven attenuation as its concentration in porewater by far exceeded its concentration in surface water. Similar patterns were observed for a larger list of suspected transformation products, of which a sotalol transformation product was tentatively identified. Overall, the established sampling methodology can be effectively used to quantify organic contaminants during low-flow conditions and is suitable for the characterization of attenuation patterns of organic pollutants in hyporheic zones.

The control of nitrite-oxidizing bacteria (NOB) challenges the implementation of partial nitritation and anammox (PN/A) processes under mainstream conditions. The aim of the present study was to understand how operating conditions impact microbial competition and the control of NOB in hybrid PN/A systems, where biofilm and flocs coexist. A hybrid PN/A moving-bed biofilm reactor (MBBR; also referred to as integrated fixed film activated sludge or IFAS) was operated at 15 °C on aerobically pre-treated municipal wastewater (23 mg_NH4-N L^–1). Ammonium-oxidizing bacteria (AOB) and NOB were enriched primarily in the flocs, and anammox bacteria (AMX) in the biofilm. After decreasing the dissolved oxygen concentration (DO) from 1.2 to 0.17 mg_O2 L^–1 - with all other operating conditions unchanged - washout of NOB from the flocs was observed. The activity of the minor NOB fraction remaining in the biofilm was suppressed at low DO. As a result, low effluent NO₃^– concentrations (0.5 mg_N L^–1) were consistently achieved at aerobic nitrogen removal rates (80 mg_N L^–1 d^–1) comparable to those of conventional treatment plants. A simple dynamic mathematical model, assuming perfect biomass segregation with AOB and NOB in the flocs and AMX in the biofilm, was able to qualitatively reproduce the selective washout of NOB from the flocs in response to the decrease in DO-setpoint. Similarly, numerical simulations indicated that flocs removal is an effective operational strategy to achieve the selective washout of NOB. The direct competition for NO₂^– between NOB and AMX - the latter retained in the biofilm and acting as a "NO₂-sink" - was identified by the model as key mechanism leading to a difference in the actual growth rates of AOB and NOB (i.e., μ_NOB < μ_AOB in flocs) and allowing for the selective NOB washout over a broad range of simulated sludge retention times (SRT = 6.8–24.5 d). Experimental results and model predictions demonstrate the increased operational flexibility, in terms of variables that can be easily controlled by operators, offered by hybrid systems as compared to solely biofilm systems for the control of NOB in mainstream PN/A applications.

Die vorliegende Anleitung soll interessierte Fachkreise und Akteure im Themengebiet zur Durchführung von Schüttelversuchen zur Bestimmung der Reinigungsleistung von Pulveraktivkohle (PAK) zur Entfernung von Mikroverunreinigungen aus kommunalem Abwasser befähigen. Die Anwendungen von PAK zur Spurenstoffelimination werden zukünftig auf Kläranlagen zunehmen, so dass sich diese Anleitung an Kläranlagenbetreiber und andere Dienstleister richtet, die einen Bedarf zur Evaluation geeigneter Aktivkohlen als auch zur Überprüfung von Produktlieferungen haben. Die vorgestellte Verfahrensweise ist durch gut ausgebildetes Klärwerkspersonal in einem gängigen Kläranlagenlabor der Eigenüberwachung der Abwasserreinigungsanlage durchführbar.
Das Dokument gibt konkrete Hinweise zur gezielten Vorgehensweise bei PAK-Auswahl, Probenahme von Abwasser, Vorbereitung und Durchführung der Versuche sowie zur Analytik und Bewertung der Ergebnisse. Es zeigt auf, welche Fragestellungen durch derartige Versuche beantwortet werden können. Das Dokument widerspiegelt die bisherigen Erfahrungen, welche an der Eawag gemacht wurden und gibt Hinweise zur Vorgehensweise ab, wobei auch auf andere Methoden und Erfahrungen hingewiesen wird. Das Dokument ist unter verschiedenen Fachleuten abgestimmt worden. Hinweise auf andere Erfahrungen oder zur Verbesserung der Vorgehensweise sowie Neuerungen im Themengebiet sind von den Autoren sehr erwünscht und richten sich bitte an die Verfasser bzw. an den VSA.
